      Teltonika TeltoCharge LED Indicators

      What do the LED indicator lights mean?

      A - White LED's rolling from bottom to top: charger is booting up

      A



      B - White pulsing LED's: charger is in standby mode and waiting for action

      C



      C - Blue LED's light up from the middle: charger does not require permission and is waiting for the EV to initiate the charging process

      F



      D - Blue LED's pulsing: charger requires authorisation, use the mobile app or swipe your RFID fob to start charging

      G



      E - Green LED's pulsing: charger is initialising the charging session

      J



      F - Green LED's rolling from bottom to top: charger is charging the EV

      K



      G - Green LED's on: charger has completed the charging session

      L



      H - Blue LED's rolling from top to bottom: charger is waiting for the scheduled charging time or if your SMART charging is toggled off, contact us at home@we-ev.co.nz

      H



      I - Four blue middle LED's pulsing: charger is waiting to add a new RFID tag

      I



      J - Four green middle LED's: RFID fob has been accepted

      O



      K - Four red middle LED's: RFID fob has been declined, add the fob via the We.EV app or contact us at home@we-ev.co.nz

      N



      L - White LED's rolling from top to bottom: charger is reserved for OCPP only, contact us at home@we-ev.co.nz

      B



      M - Yellow pulsing LED's: charger is in standby mode with default settings, contact us at home@we-ev.co.nz

      D



      N - Yellow LED's on: charger is not charging, simplified charging sequence is required, contact us at home@we-ev.co.nz

      E



      O - Purple LED's on: charger requires ventilation, contact us at home@we-ev.co.nz

      M





      Red LED Indicators - Errors and Warnings

      Contact us at home@we-ev.co.nz for help,If possible, please provide a photo or a short video clip showing the LED indicators, along with a description of the circumstances when the error or warning lights first appeared.



      A - Single orange LED on top: warning of either temperature, current, energy meter issues

      error H



      B - Single red LED on top: input voltage error

      error A



      C - Single red LED second from top: output voltage/current error

      error B



      D - Single red LED third from top: current leakage detected

      error C



      E - Single red LED third from bottom: connectivity error

      error D



      F - Single red LED second from bottom: temperature error

      error E



      G - Single red LED at the bottom: internal errors

      error F



      H - Pulsing red LED's: faulty connection to EV

      error G
